Additional information
Function | Absolute encoder |
---|---|
Outer diameter | ⌀115 mm |
Shaft type | Solid shaft |
Shaft dimension | ø11 mm key way |
Electrical connection | Cable, Terminal box, 12 pin Con FM (M23 type) |
Connection direction | Radial |
Power supply | 10-30 Vdc |
Electrical interface | CANopen |
Surface treatment | Stainless steel |
Temperature range | -30º- 70ºC |
Vibration | 10g |
Chock | 100g |
Flange type | B10 Euro flange |
